Precautions for reducer with motor
Precautions for reducer with motor
1. The use of the reducer is to increase the torque. For the life of the reducer, the torque calculation is very important, and it is necessary to pay attention to the maximum torque value (TP) of the acceleration, that is, the peak torque of the reducer, whether it exceeds the reducer The maximum load torque.
2, In the case of knowing the peak torque, select the number of stages of the motor . What should be considered in this is a speed ratio.
3. In the case of a certain speed ratio , consider the service factor and safety factor. The reference value of this service factor is different in each industry field, and some reducer manufacturers use the shaft power when selecting a reducer through the motor. Calculated, this should also be paid attention to.
The landlord said how much power should be matched with how much reducer, the following coefficients should be considered
1 The ambient temperature is generally required to be -10~~40 degrees
2 altitude
3 installation space
4 wind value load start times per hour
5 hourly duty cycle
6 lubricating oil form
If the landlord has determined the output form and installation form of the reducer, you can simply select the type, which is suitable for general situations.
Shaft power (generally 0.8 of the motor power, in some cases it cannot reach this value), and then the * service coefficient (generally above 1.5) is enough, refer to the sample, through the speed ratio, the number of motor stages, and the detection ratio to get The result is a slightly larger reducer power box, which is the selection. For special circumstances, please consult the manufacturer.
