Rated power 额定功率(KW):

5

Peak power峰值功率 (KW):

12.5

Rated Voltage 额定电压DC(V):

60

voltage range电压范围 DC(v) :

48-75

Rated current 额定电流(A):

104

Peak current最大允许电流(A):

400

Rated speed 额定转速(r/min):

2800

Peak speed最高转速(r/min):

3600

Rated torque 额定扭矩(N.m):

17.1

Peak torque 峰值扭矩(N.m):

100

Efficiency电机的效率%:

80%

Duty工作制 :

S2-60min

weight重量kg):

39
