Rated power 额定功率(KW):

4

Peak power峰值功率 (KW):

Rated Voltage 额定电压DC(V):

48

voltage range电压范围 DC(v) :

Rated current 额定电流(A):

104

Peak current最大允许电流(A):

Rated speed 额定转速(r/min):

2800

Peak speed最高转速(r/min):

4000

Rated torque 额定扭矩(N.m):

13.6

Peak torque 峰值扭矩(N.m):

Efficiency电机的效率%:

Duty工作制 :

S2-60min

weight重量kg):

35
