Series ZYT PM DC Motor
Date：2024-08-26 Author：XINDA MOTOR
ZYT series permanent magnet DC motor adopts ferrite permanent magnet excitation system and is closed and self-cooled. As a low-power DC motor, it can be used as a driving element in various devices.
Usage conditions
1. Altitude not exceeding 4000m:
2. Ambient temperature: -25°℃~ +40°C;
3. Relative humidity: <95% (at +25℃)
4. Allowable temperature rise: not exceeding 75K (at 1000m above sea level).
