Xiangdian Group overcomes the problem of high efficiency and energy saving
In recent years, Xiangdian Group has focused on the core business of "three electric power" and actively promoted the transformation and upgrading of products and technologies. A number of technologies and equipment have been shortlisted in the recommended catalog of national energy-saving technology and equipment, and many products have passed the certification of China's energy-saving products. Systematic solutions for environmental protection, green, high efficiency and energy saving.
![](/uploads/2023/02/092231427908.png)
Demonstrating new achievements in the industrial field
Industry is the key field of energy saving and emission reduction. Xiangdian Group started the major research on high-efficiency and energy-saving motors as early as 2008. At present, Xiangdian Group has successively overcome five major problems such as optimizing the rotor structure, innovating the insulation process, and more than 30 key technologies, and successfully developed a green high-efficiency high-voltage with higher power density, lower center height, smaller volume, and higher energy efficiency. Motors and ultra-green series motor products, the motor efficiency has reached 96.91%, and the key technical indicators have reached the international leading level.
![](/uploads/2023/02/092231546142.jpg)
High-efficiency high-voltage energy-saving motor products launched by Xiangdian Group (photo courtesy of Xiangdian Group)
Up to now, Xiangdian Group has developed more than 3,000 high-efficiency and energy-saving motor models, and is one of the enterprises shortlisted for the largest number of national "energy-saving products benefiting the people". The running high-efficiency and energy-saving motors save 1.6 billion kilowatt-hours of electricity annually, which is equivalent to saving 4.6 million tons of standard coal and reducing carbon dioxide emissions by 9.2 million tons.
In March 2022, the first domestic high-efficiency permanent magnet direct drive system for mining flotation machines independently developed by Xiangdian Group passed the commissioning and customer acceptance, and the energy saving rate of the transformed system reached more than 35%. Taking 75kW equipment as an example, a single equipment can save about 150,000 yuan in electricity costs and reduce carbon emissions by about 209 tons a year.
Xiangdian Group has also led the formulation of the industry standard "Technical Specifications for Green Design Product Evaluation - High Power Density High Voltage Three-phase Cage Asynchronous Motor", and has completed the development of a first-class energy-efficient motor and an ultra-efficient ultra-high power density motor, which are popularized and applied in the industry It has a broad market prospect.
Demonstrate new responsibilities in the field of electric energy
While continuing to give full play to the advantages of wind power generators, wind power auxiliary machines (pitch change, yaw), and nuclear main pump motors, Xiangdian Group has continuously strengthened the technology development, market development and engineering generalization of energy-saving products such as energy storage equipment and new energy power stations. package business.
In April 2022, my country's first 1-megawatt flywheel energy storage device developed by Xiangdian Group completed installation, commissioning, and grid-connected application on Qingdao Metro Line 3. This product currently has the largest single power in China, has completely independent intellectual property rights, and its various performances have reached the world's advanced level, breaking the foreign technology monopoly in this field. It is estimated that after the comprehensive promotion and application of Qingdao Metro, it can save 15% of traction energy consumption, 50 million kilowatt-hours of electricity per year for the line network, and reduce carbon dioxide emissions by about 50,000 tons per year.
Xiangdian flywheel energy storage technology solves the problem of "stuck neck" abroad (photo courtesy of Xiangdian Group)
Low-temperature waste heat power generation can reduce energy consumption and improve energy utilization. In May 2022, the prototype of the 315kW ORC low-temperature waste heat power generation system independently developed by Xiangdian Group successfully realized power generation. ORC is an effective technical way to recover low-temperature heat energy. The ORC system developed by Xiangdian has a power generation efficiency of 84%. Such an ORC system can provide 1.8 million kWh of clean electricity every year, which is equivalent to reducing carbon dioxide emissions by more than 1,700 Ton.
The low-temperature waste heat power generation system independently developed by Xiangdian (photo courtesy of Xiangdian Group)
In addition, Xiangdian Group also accelerates the construction of professional talent teams in the fields of wind power operation and maintenance, engineering construction, etc., and strives to expand projects such as green building photovoltaic roof power stations, wind power stations, solar photovoltaic stations, general contracting of water conservancy and water services, and waste treatment power stations. General contracting project construction to create a new growth pole.
Dare to make new breakthroughs in the field of transportation
The intelligent, green and high-end mining equipment has become the general trend. Xiangdian Group independently developed the world's first 120t pure electric AC drive electric wheel mining dump truck. Compared with fuel dump trucks of the same tonnage, the energy cost is reduced by 70%, and the operating cost is reduced by 40%. A single vehicle can reduce carbon emissions every year. 1500 tons.
The 120-ton pure electric AC drive electric wheel mining dump truck developed by Xiangdian Group (photo courtesy of Xiangdian Group)
In March 2022, the 100-ton dump truck electric energy substitution research and application project undertaken by Xiangdian Group successfully passed the project acceptance. The successful R&D and production of Xiangdian's 120-ton pure electric dump truck has filled the gap in the domestic 100-ton pure electric off-highway mining dump truck, and also marks the realization of the fully autonomous electrification of domestic 100-ton mining dump trucks.
Transportation is one of the key areas of carbon emission in my country. The permanent magnet traction system and high-speed magnetic levitation traction system developed by Xiangdian Group will greatly promote the low-carbonization level of rail transit vehicles and improve energy-saving efficiency.
At present, the key core technologies such as motors and track control systems for high-speed maglev rail transit systems independently developed by Xiangdian Group, and their engineering technologies have been verified. For example, a product developed by Xiangdian uses a permanent magnet synchronous motor instead of an internal combustion engine as the drive system, which can meet the requirements of high-speed traction and low-speed grinding operations at the same time. Compared with traditional internal combustion locomotives, energy consumption can be reduced by 10%.
In December 2021, the first electric passenger car of the first phase project of the West Ring Line of Changzhou-Zhuzhou-Tanzhou Intercity Rail Transit was successfully delivered. The traction motors on this car were all manufactured by Xiangdian Group. Xiangdian's traction motor has the advantages of small size, light weight, low noise and high efficiency, and it has also realized the localization of motor insulation structural materials for the first time.
In the field of ships, the all-electric power system developed by Xiangdian Group has overcome the new large-capacity high-speed integrated power generation technology, using new permanent magnet propulsion or new induction propulsion as the power unit, which greatly improves the ship power layout. It has comparative advantages in terms of mechanical noise, economy, and environmental protection. The prime mover always works in the best area, and the carbon and nitrogen oxide emissions in the combustion are less.
In January 2022, the 123.8m coastal self-unloading sand carrier DC integrated power system developed by Xiangdian Group was successfully rolled out. This system can greatly reduce the number of marine diesel engines, improve operating efficiency, reduce operating and maintenance costs, and greatly reduce carbon emissions.
Xiangdian Group proposed that by the end of the "14th Five-Year Plan", the efficiency of motors will be increased by 1%-2% on the existing basis, and the efficiency of energy-saving transformation systems will be increased by more than 20%, reaching the global leading level. At the same time, it will continue to develop in the "double carbon" goal New products and new technologies in the market field that conform to the market characteristics of the "three new and three new". At that time, it will continue to contribute to the reduction of carbon dioxide emissions in my country and the formation of a green development model. "Xiangdian" power.
