Analysis of Naming Rules of AC Geared Motor
Date：2023-01-27 Author：XINDA MOTOR
For example: YY 70 - 10 CZ
Among them: YY indicates the motor category ----- YY: one-way capacitor operation induction motor ; YN: one-way capacitor operation reversible motor ;
70 indicates frame size --- ----60=Ф60mm, 70=Ф70mm, 80=Ф80mm, 90=Ф90mm, 100=Ф100mm;
10 means output power -------6=6W, 10=10W, 15=15W, 25=25W , 40＝40W, 60＝60W, 90＝90W, 120＝120W, 140＝140W;
C indicates the shaft form -------- C: gear shaft; W: worm shaft; G: optical axis;
Z Indicates attached devices ---------- Z: with damping disc; C: with tachometer generator; D: with electromagnetic brake; F: with fan blades.
